Stainless Steel Wire Mesh
Stainless steel fence wire was made of stainless steel wire through warp and weft woven. 302 SS, 304 SS, 304L SS, 310 SS, 316 SS, 316L SS, 317L SS, 321 SS, 330 SS, 347 SS, 410 SS, and 430 SS is the material grades of stainless steel wire mesh we produce. and our product mainly used for the filtration and screening of gas, liquid and solid, the separation of media and so on.
Stainless Steel Fence Wire
Stainless steel fence wire is strong and durable. By its very nature, stainless steel fence wire does not require additional surface treatments such as galvanizing or PVC to protect it. The wire itself is extremely resistant to rust, corrosion, and harsh chemicals.
If you need to use welded mesh or fencing in areas that will be exposed to corrosive substances for long periods of time, stainless steel products will meet your needs. Type 316 is recommended for salt water environments because it has higher corrosion resistance than Type 304.
Features and Benefits:
Ultra-long service life, which is longer than that of galvanized products before welding
Extremely strong, durable and resistant to rust, corrosion and harsh chemicals
Lowest long-term cost of ownership in harsh conditions (higher initial cost is offset by lower repair and replacement frequency)
Ideal for hard-to-access areas for rust and corrosion
Application
Like almost all wire mesh and wire cloth, stainless steel welded wire mesh is suitable for construction, agriculture, commercial and industrial applications. Here are some popular uses for T 304 SS and T 316 SS welded wire mesh:
Infill panels and railing systems
Industrial Fans and Machine Guards
safe enclosure
Animal Retention (Cage)
small animal control
decorative sign
room divider
wall covering
ceiling
Vents and Soffit Screens
Basket making
food application
Shelves and Storage
Birdhouses and Bird Screens
industrial separation
Parameters
Material: SS 201, 202, 304, 316, 316L, 321, 430, 310S, 2205, 2207,904L etc.
Mesh count: 2mesh, 10mesh , 20mesh, 40mesh, 60mesh, 80mesh, 100mesh, 200mesh, 300mesh, 400mesh etc
Plain weave: 0.5X0.5mesh to 635X635 mesh;
Twill weave: 20x20mesh to 400x400mesh;
Plain dutch weave: 10X64mesh to 80X700mesh;
Reversed dutch weave: 48x10mesh to 720x150mesh.
Roll width 1m, 1.22m, 1.3m, 1.6m ,2m, 3m, customization available .
Roll length 30m, 60m, customization available
Special size and specification are available according to customers requirment.
Over 20000 rolls Stainles Steel Wire Mesh in Stock
If you are interested in our stainless steel fence wire, please contact us.
Stainless steel wire mesh was made of stainless steel wire through warp and weft woven. 302 SS, 304 SS, 304L SS, 310 SS, 316 SS, 316L SS, 317L SS, 321 SS, 330 SS, 347 SS, 410 SS, and 430 SS is the material grades of stainless steel wire mesh we produce. and our product mainly used for the filtration and screening of gas, liquid and solid, the separation of media and so on.
Stainless Steel fence wire Specification
Meshes perLinear inch | Wire diameter | Width of opening | Open area | ||
inch | mm | inch | mm | percent | |
1×1 | .157 | 4.0 | .84 | 21.4 | 71.0 |
2×2 | .118 | 2.5 | .38 | 10.2 | 64.0 |
3×3 | .079 | 2.0 | .25 | 6.4 | 58.0 |
4×4 | .063 | 1.6 | .187 | 4.75 | 56.0 |
4×4 | .047 | 1.19 | .203 | 5.16 | 65.9 |
5×5 | .055 | 1.4 | .14 | 3.68 | 52.0 |
6×6 | .047 | 1.2 | .12 | 3.03 | 51.0 |
8×8 | 0.43 | 1.1 | .08 | 2.08 | 42.0 |
10×10 | .039 | 1.0 | .06 | 1.54 | 36.0 |
10×10 | .020 | .51 | .080 | 2.03 | 64.0 |
12×12 | .023 | .584 | .060 | 1.52 | 51.8 |
12×12 | .020 | .508 | .063 | 1.60 | 57.2 |
14×14 | .023 | .584 | .048 | 1.22 | 45.2 |
14×14 | .020 | .508 | .051 | 1.30 | 51.0 |
16×16 | .018 | .457 | .0445 | 1.13 | 50.7 |
18×18 | .017 | .432 | .0386 | .98 | 48.3 |
20×20 | .020 | .508 | .0300 | .76 | 36.0 |
20×20 | .016 | .406 | .0340 | .86 | 46.2 |
24×24 | .014 | .356 | .0277 | .70 | 44.2 |
30×30 | .013 | .330 | .0203 | .52 | 37.1 |
30×30 | .012 | .305 | .0213 | .54 | 40.8 |
30×30 | .009 | .229 | .0243 | .62 | 53.1 |
35×35 | .011 | .279 | .0176 | .45 | 37.9 |
40×40 | .010 | .254 | .0150 | .38 | 36.0 |
50×50 | .009 | .229 | .0110 | .28 | 30.3 |
50×50 | .008 | .203 | .0120 | .31 | 36.0 |
60×60 | .0075 | .191 | .0092 | .23 | 30.5 |
60×60 | .007 | .178 | .0097 | .25 | 33.9 |
70×70 | .0065 | .165 | .0078 | .20 | 29.8 |
80×80 | .0065 | .165 | .0060 | .15 | 23.0 |
80×80 | .0055 | .140 | .0070 | .18 | 31.4 |
90×90 | .005 | .127 | .0061 | .16 | 30.1 |
100×100 | .0045 | .114 | .0055 | .14 | 30.3 |
100×100 | .004 | .102 | .0060 | .15 | 36.0 |
100×100 | .0035 | .089 | .0065 | .17 | 42.3 |
110×110 | .0040 | .1016 | .0051 | .1295 | 30.7 |
120×120 | .0037 | .0940 | .0046 | .1168 | 30.7 |
150×150 | .0026 | .0060 | .0041 | .1041 | 37.4 |
160×160 | .0025 | .0635 | .0038 | .0965 | 36.4 |
180×180 | .0023 | .0584 | .0033 | .0838 | 34.7 |
200×200 | .0021 | .0533 | .0029 | .0737 | 33.6 |
250×250 | .0016 | .0406 | .0024 | .0610 | 36.0 |
270×270 | .0016 | .0406 | .0021 | .0533 | 32.2 |
300×300 | .0015 | .0381 | .0018 | .0457 | 29.7 |
325×325 | .0014 | .0356 | .0017 | .0432 | 30.0 |
400×400 | .0010 | .0254 | .0015 | .0370 | 36.0 |
500×500 | .0010 | .0254 | .0010 | .0254 | 25.0 |
635×635 | .0008 | .0203 | .0008 | .0203 | 25.0 |
